ultra thin light box power supply

12V & 24V & 48V options available to ultra thin light box power supply. Adjustable indoor ultra thin light box power supply 12V & 24V & 48V with an input voltage of 170~240VAC to supply lighting based on 12V & 24V & 48V LED technology. The maximum power capacity of ultra thin strip light box transformer is 400W.

The led strip light power supply can be easily connected to LED strips through the front screw terminals or used to power other electronic devices. The led strip power supply has 1 output.

Used in conjunction with a voltage regulator, led strip power supply allows you to change the light intensity of the strip.

Available Outputs:

• 60W, 100W, 120W, 150W, 200W, 250W, 300W, 360W, 400W

12V & 24V & 48V led strip power supply Features

12V & 24V & 48V options available to ultra thin light box power supply

Charcoal black high-quality anodized aluminum construction

High density PCB with SMT process

Thickness within 29mm

Smaller size with bigger power ( 60W to 400W )

Superior heat dissipation with fanless silent design

Short circuit, overload, overvoltage, overcurrent and leakage protection

CE & RoHS & FCC listed

ODM & OEM supported and Fast delivery

12V & 24V & 48V led strip power supply Specifications

AC input voltage range: 85-132V / 170-264VAC Selected by Switch

Input frequency: 47-63Hz

Output voltage: 12V & 24V & 48VDC±1%

Inrush current: cold start, 20A/115V, 40A/230V

Input leakage current: <0.7mA / 230V

Line regulation (Full Load): <± 0.5%

Output overload protection: 110-130% Constant Current, Auto Recovery

Output over voltage protection: 115-150%

Withstand voltage: I/P-O/P: 3.0KVAC/1min; I/P-F/G: 1.5KVAC/1min; O/P-F/G: 0.5KVAC/1min

Rise time: 50ms@full load (typical)

Hold up time: 20ms@full load (typical)

Operating temp.& humidity: -10°C to 50°C (14°F - 122°F), 20%-93%RH (non-condensing)

Storage temp.& humidity: -20°C to 85°C (-4°F - 185°F), 20%-93%RH (non-condensing)

MTBF: 100,000 hours

For more information, please contact us.
