12V 15A / 20A / 30A 18 Fused UPS Power Supply Box

POWER SUPPLY > UPS Power Supply Box > 12V 15A / 20A / 30A 18 Fused UPS Power Supply Box

12V 15A / 20A / 30A 18 Fused UPS Power Supply Box

    • 1
    • 2
    • 3
    • 4
    • 5
The Shampower 18 channel UPS Power Supply Box is the AC/DC security power supply, allowing the universal input range between 90VAC to 240VAC. In addition to the primary output, there is a charger output, with a smaller rated current, providing the backup application the security access systems normally need.

The Shampower 18 channel UPS Power Supply Box delivers efficiency up to 86%, it can operate with air convection under -20℃~ 70℃. The 18 channel UPS Power Supply Box is designed with thorough alarm features, including AC OK and battery low signaling. Robust fault response and indication also includes gradual shutdown on output overload as well as immediate shutdown on output short, signaled by flashing red LED and with auto-recovery once output short or overload is removed. The power input and power output are enclosed in one heavy-duty, easy-to-install enclosure. As a result, a Shampower 18 channel UPS Power Supply Box can replace several separate individual power sources.

Available Outputs:

• 18 Outputs：

  15A@12VDC,

  20A@12VDC,

  30A@12VDC with enclosure



18 Channel UPS Power Supply Box features:

1) 18 Outputs: 10A@12VDC, 15A@12VDC with enclosure

2) AC power failure supervision relay

3) Main power switch to turn on/off power to outputs

4) Each output individually PTC fused

5) Battery failure supervision relay

6) Selectable delay timer (5 sec., 10 sec,) for AC failure supervision relay via DIP switch

7) Board designed with overload and short-circuit protection, including automatic shutdown and LED overload indicator

8) Over-current fuse-protected AC input

9) Built-in backup battery charger (12V 7Ah & 10Ah back-up battery is optional)

10) Automatically switch to backup battery if AC fails

11) Individual AC input and DC output LED status indicators

12) Alarm signal for AC OK and Battery low

13) Battery low protection / Battery reverse polarity protection by fuse

14) Universal AC input / Full range



18 Channel UPS Power Supply Box specifications:

1) Input Voltage: 110~240VAC

2) Output Voltage: 12VDC selectable via DIP switch

3) Adjustable Output: 11~15 @ 12VDC setting via VR switch

4) No. of Outputs: 18 channels

5) Supply Current: 15A@12VDC / 20A@12VDC / 30A@12VDC

6) AC Input Fuse Rating: 3.15A ( glass fuse )

7) LED Status Indicator: AC input ( Green ), DC Output ( Red )

8) AC-Fail Relay Delay Timer: Selectable @ 5sec or 10sec via DIP switch



Dimensions:    11.2" x 8.3" x 3.7"(15A); 11.2" x 8.3" x 3.7"（20A / 30A）

Gross weight:  1.8kg

Quantity per carton: 10 pcs/ctn



18 Channel UPS Power Supply Box Applications:

1) Security system

2) Emergency lighting system

3) Alarm system

4) UPS system

5) Central monitoring system

6) Access system
